Atom AT9039 Flush TRI 8W LED Downlight

by Atom Lighting
SKU: AT9039/WH/F/TRI
$19.00
Atom AT9039 Flush TRI 8W LED Downlight
Atom AT9039 Flush TRI 8W LED Downlight
Atom AT9039 Flush TRI 8W LED Downlight
Atom AT9039 Flush TRI 8W LED Downlight
Atom AT9039 Flush TRI 8W LED Downlight

Atom AT9039 Flush TRI 8W LED Downlight

by Atom Lighting
SKU: AT9039/WH/F/TRI
$19.00
Fast Shipping from $7.90
Secure payments
(0 in cart)
Tax included.Shipping calculated at checkout.

8W LED Downlight with dimmable integral driver – TRI colour with flush Diffuser

Features

  • Built-in Driver
  • Ideal for Residential, retail, showroom and decorative
  • IC-4 Rated – According to AS/NZS605982.2:2016
  • Seamless Look

Mechanical

Adjustability Fixed
Body Material Aluminium
Product Finish Powdercoated
Fitting Colour White
IC Rating IC-4
IC-4 rating has been conducted at the products maximum working Temperature Range (C) in line with Australian standards. This provides the required safety when covered with insulation and used in Australian Environments.
Installation Type Recessed
IP Rating IP54 Front Face Only

Electrical

Electrical Rating Class II
Input Frequency 50 Hz
Input voltage 230Vac
In Australia the Input voltage is defined as 230Vac -6%/+10%. This effectively means that the voltage range of these products are 216Vac - 253Vac or 240V +6%
Maximum Wattage 8 W
Switch Type Inline
Working Temp Range 5 to 40 °C

Lamp

Beam Angle 90 °
CCT Configuration TRI-CCT
CRI >80
LED Type Diffused
Number of Lamps 1

LED Lifetime

LED Lifetime 36000 hrs
This is the Reported LED Lifetime in Hours based on TM-21. Atom does not list the projected or calculated LED lifetime, which is normally longer as TM-21 Addendum B explicitly states "The Calculated and Projected Lp(Dk) are not to be reported". This Lifetime refers to the life of a single LED however the system life is longer since the probability and binomial distribution of all LEDs in the system means that the average led is performing above the specification and compensates for the LEDs falling below.
LED Lifetime Rating L70B10 (6k)
TM-21 Test Hours 6000 hrs

Colour temperature

6 Watts
Warm White (3000) 670 lm
Cool White (4000) 750 lm
DayLight (5700) 700 lm

Driver

Dimmable Yes
Driver Included Yes
Integrated Driver Yes
Driver Type Dimmable ( Phase cut)
Wiring Type Non rewireable Flex & Plug

Compliance

Product Design Life 10 years
The product design life relates to the total product life which includes LEDs, drivers and the enclosure. This is different to the LED lifetime which only refers to the economical lifetime of the LEDs at which time the lumen output has dropped below the L Value. The product design life is calculated at the maximum ambient or working temperature of the product and takes into account the Daily Use.
Daily Use 10 hrs
The Daily Use is the recommended time required to meet the product's design life. Installations can exceed this time, however the product design life will be reduced proportionally.
Standards
  • AS/NZS 60598.1
  • AS/NZS 60598.2.2
  • AS/NZS 61347.1
  • AS/NZS 61347.2.13
  • AS CISPR 15

Warranty

Commercial Use Warranty 3 RTB (Total 3 Years)
Domestic Use Warranty 3 (Yr) RTB
Operational Lifetime 30000 hrs
