Ektor 17740 Razor-Flex Pro Slimline Emergency Edgelit Exit 24M

by Ektor Lighting
SKU: EV-RAZOR-FLEX-PRO-24M
$301.00
Ektor 17740 Razor-Flex Pro Slimline Emergency Edgelit Exit 24M
Ektor 17740 Razor-Flex Pro Slimline Emergency Edgelit Exit 24M
Ektor 17740 Razor-Flex Pro Slimline Emergency Edgelit Exit 24M
Ektor 17740 Razor-Flex Pro Slimline Emergency Edgelit Exit 24M
Ektor 17740 Razor-Flex Pro Slimline Emergency Edgelit Exit 24M
Ektor 17740 Razor-Flex Pro Slimline Emergency Edgelit Exit 24M
Ektor 17740 Razor-Flex Pro Slimline Emergency Edgelit Exit 24M
Ektor 17740 Razor-Flex Pro Slimline Emergency Edgelit Exit 24M

Ektor 17740 Razor-Flex Pro Slimline Emergency Edgelit Exit 24M

by Ektor Lighting
SKU: EV-RAZOR-FLEX-PRO-24M
$301.00
Fast Shipping from $7.90
Secure payments
(0 in cart)
Tax included.Shipping calculated at checkout.

Features

  • Single and double-sided decals
  • Soft-start charger to reduce building load
  • Surface mounted exit sign with remote driver
  • Wall or ceiling mount
  • Fast emergency switch-over (<0.5s) for high-task areas
  • Long life electronics
  • 10 years design life at max. ambient
  • High Quality Lithium battery (LiFePO4) and smart charger
  • DALI (IEC 62386-202) DT1
  • Self test (AS2293/IEC62034)
  • Ektor wired monitored system
  • Fully compliant (AS/NZS 2293)

MECHANICAL

Body Material Polycarbonate
Diffuser Material PMMA
Fitting Colour Frosted
Installation Type Surface mount
IP Rating IP20

ELECTRICAL

Electrical Rating Class II
Input Frequency 50 Hz
Input voltage 230Vac
In Australia the Input voltage is defined as 230Vac -6%/+10%. This effectively means that the voltage range of these products are 216Vac - 253Vac or 240V +6%
Maximum Wattage 3.7 W
Standby Power 1.7 W
Standby power for non-maintained/switched maintained emergency devices is measured when the light is off and the charger is in standby mode. For maintained emergency devices, standby power is measured when the light is on and the charger is in standby mode. Typically, charging occurs for the first 16 hours after the device is powered or after a battery discharge.
Working Temp Range 0 to 40 °C

LAMP

CCT Configuration Single
CRI >80
Lamp/LED Current 75 mA
Lamp/LED voltage 9 V

COLOUR TEMPERATURE

CCT 6000K
LED Wattage 0.75 W

DRIVER

Dimmable No
Driver Included Yes
Integrated Driver No
Driver Type DALI DT1 Emergency
Wiring Type Re-wireable terminal block (5 pin)

EMERGENCY (EM SUFFIX)

Replacement Battery Code 01302
Emergency Classification C0:E4, C90:E4
Emergency Control DALI Monitored (DT1)
DALI Monitored ~ Supports Emergency test and monitoring over DALI (IEC62386) with full compliance to IEC62386-202.
Decal Size 300 x 150 mm
Emergency Duration 90 mins
Emergency Mode Maintained
Emergency Output Power 750 mW
Viewing Distance 24 m

COMPLIANCE

Product Design Life 10 years
The product design life relates to the total product life which includes LEDs, drivers and the enclosure. This is different to the LED lifetime which only refers to the economical lifetime of the LEDs at which time the lumen output has dropped below the L Value. The product design life is calculated at the maximum ambient or working temperature of the product and takes into account the Daily Use.

WARRANTY

Commercial Use Warranty 5 RTB (Total 5 Years)
