Description
- Recessed SMD LED fixed downlight with a slim design and stepped opal polycarbonate diffuser for uniform lighting distribution
- Aluminium profile provides excellent thermal management for exceptional heat dissipation
- An ideal lighting solution for residential and commercial applications
- Colour temperature can be selected via a switch at the rear of the luminaire, enabling users to switch between 3000K (warm white), 4000K (cool white) and 5700K (daylight) CCT
- Supplied with remote flicker free Leading & Trailing Egde dimmable driver
Physical Characteristics
Trim Colour：White|Black
Dimensions：⌀145 X 53 (H) mm
Weight：400 g
Cutout：Circle - 120 - 130 mm
Spring Height：35 mm
General Characteristics
Family：Trend For Trade, Multiled
Surface：Ceiling
Mounting：Recessed
Insulation Contact：IC-4
Ingress Protection：IP54
Warranty：3 Years
Technical Characteristics
LED Power：12W
LED Type：SMD
LED Lumen Output*：1,415 lm
Efficacy*：Up to 120 lm/W
CCT Technology：Tri-colour Selectable
Colour Temperature：3000K, 4000K, 5700K
Colour Technology：CRI 85+ Standard
Colour Deviation：SDCM ≤ 3
Lifetime：50,000 hours (L70)
Beam Angle：Wide
System Power：11.7W Typical
Driver Model：Trend DR-DTL12 (L&T)
Input：200-240V AC 50 Hz
Power Factor：>0.95
Driver：Leading & Trailing Edge
