Trend VSTR3 IP67 Step Light

• Recessed IP67 rated round LED step light with asymmetric beam distribution
• Designed to provide an aesthetic lighting solution for way-finding and architectural applications
• Optional recessed mounting canister included
• CRI 80+ available in 3000K CCT option
• Compatible driver models available upon request
• Requires 12V DC 250mA constant voltage driver

Physical Characteristics

Trim Colour：White
Dimensions：⌀80 X 36 (H) mm
Weight：213 g
Cutout：Circle - 60 mm

General Characteristics

Technical Characteristics*

LED Power：3W
LED Type：COB
LED Lumen Output*：140 lm
Luminous Flux*：82 lm
Efficacy*：27.33 lm/W
Colour Temperature：3000K
Colour Technology：CRI 80+ Standard
Colour Deviation：SDCM ≤ 3
Lifetime：50,000 hours (L80)
Beam Angle：Asymmetric
System Power：3W Typical
